So you’ve decided to make shutters. Good for you! Today we are going to get busy building. By now you should have determined the finished dimensions of your shutters, style, made a bill of goods for lumber, purchased the wood – nice and straight, and set up a work area with all the critical tools. Whew! Once you get the wood home, make sure that it is dry. Some of the pieces we bought were damp. They will warp so let them dry out before you start building. In addition to proper tools, you will also need good wood screws, eye protection, gloves, and metal plates to attach the breadboard tops. I do not have a picture of the plates, the are roughly 8-10 inches long and 1/5 or 2″ wide, flat metal with holes punch through them on either side of the center. DH says that they are standard at any big box store and there is a picture further on down in this post.
Step 1 - Measure, mark, remeasure, cut, set aside. We made shutters for six 60 x 30 windows. Each shutter required four 60″ boards x 2/window= 48 60″ boards. We cut them and set them against a garage wall. Note **We chose NOT to precut the battens or bread box tops. As each board is slightly off the standard four inch width so that meant that each shutter was different. Sine we wanted a very custom look, we did not cut the top or battens until the four main boards were assembled.
Step 2 – Sand until smooth on both sides and the ends.
Step 3 – Assemble – Place the four boards side by side making sure that the tops are flush. Use clamps/vices to hold them tightly together. Measure the width of the shutter. This will be the width to cut for the two battens.
Step 4 – Cut and prepare the battens. At this point you will need to decide the spacing on your screws. Dh chose to counter sink the screws and cover the holes with these nifty wooden pegs we found at Michaels. Once you decide the spacing mark the hole locations on a stiff piece of carboard or plastic the size of your standard batten which you will use as a template. Since we knew that each batten would be roughly 14.5″ wide we cut our template the same length and width as our ideal batten, poking holes through the template at the point where the screws will go. After you cut your battens, lay your template over the wood and mark the drill points on each.
Step 5 – Route out holes for screws deep enough to allow peg covers, drill pilot holes slightly smaller than screws. You might want to use a piece of scrap wood to practice routing out the right size hole for the covers so they will be easy to pop in. Lessons learned the hard way. :-)
Step 6 – Attach battens - Determine the standard distance the battens will be from the bottom and top of your shutter. Using the builder’s square, mark location. LIne up batten with line and clamp tightly. Attach battens to shutter body with screws.
Step 7 – Add the Breadboard top – Measure top of shutter for breadboard (bb). Technically you could measure and cut this at the same time as you measure and cut for the battens. Whatever works for you. It is very important that the four pieces of the shutter are as aligned as possible as you will be attaching the breadboard directly on top and you do not want a gap. To attach the bread board, flip your shutter “face” down, hold your bb top flush. Lay your attachment plate over the edge of the bb piece so that some of the holes are on the shutter side and the others are on the bb. Mark where the holes are. Sometimes we clamped the bb piece to the shutter, but often I just held it tight. This is a two person project! Screw the plate into place. Now your shutter is assembled!
Step 8 – Cover counter sunk screw holes with wood peg covers. We put a small dot of liquid nails in the hole and used a rubber mallet to tap them in.
Step 9 – Finishing touches – prime your finished shutters with a SANDABLE oil based primer. Tint the primer if you are going to paint the shutters a dark tone. Do not neglect to paint the back side of the shutters or they will ROT! Let them dry completely and sand until smooth. Typically painters will use a semi-gloss paint on shutters so they will look much better if you make sure they are smooth. Paint with final coats of good exterior paint – at least 2 as they will take a beating from the weather and secure to the house with long screws.
Step – 10 – Step back and ask each other why you didn’t do this sooner!
PS – Please let me know if you have any specific questions. Best of luck!
Building DIY shutters for an entire house is an undertaking, but it is doable and very rewarding. Last spring as part of our house remodel, my dh and I built shutters for 10 windows on the front of our Colonial Revival home. It definitely helped with our curb appeal! Last week Terri Sue asked for a few how toos and I realized that in all the summer kitchen craziness I never posted any information. Je suis desolee! So here we are. In Part I I laid out the initial planning steps and today I am going to cover a few important tools and tomorrow we’ll get down to the nitty gritty of cutting and assembly. I hope that it will be helpful!
Having the right tools can determine whether or not you are able to complete your project and keep your sanity. Shutters do not require a woodworking studio but some common work horses that you will use for a variety of other DIY projects. Here are a few you should have on hand:
sander – belt or orbital either works
saw – preferably miter or table saw. A circular saw will work but not if the blade is not sharp enough. We started with a circular saw and decided to buy a table saw on Craigslist. A miter saw would have been great too.
drill – make sure you have a bit that allows you to counter sink screws if you plan to cover the holes with wooden peg covers. If it is battery operated, always have a battery charging. This project will eat batteries.
clamps and vices – Once you determine the width of your shutters MAKE SURE you have several vices/clamps that open to that width. We found that often the boards were either not perfectly straight i.e. warped or not of perfect width so when we were putting a group of four together we often had to line up each end and clamp them together before attaching the battens. Otherwise they splayed apart. Very irritating, but clamps gave us the proverbial upper hand. We purchased a set from H*Dpot that included both pinching clamps and sliding vices. We then also bought a few wide clamps that you screw tight. We were being cheap and while they worked, I would have preferred the sliding variety.
A builder’s square – you will need a square to keep everything lined up or you will have crooked shutters. Take my word for it. Get one that is big enough to lay across the width of your shutter i.e. at the top so that it extends down the length. Many people only have a small plastic square. It will not suffice.
A work table – No, you do not need to buy one, but have a large working area that is comfortable and will hold your largest shutter. Saw horses with sturdy plywood should work. We also had a smaller table to hold our tools so we did not knock over the drill when we repositioned the shutters. Having a table to which you can clamp the shutter occasionally is also useful.
Tomorrow, let the building begin!
Do you have shutters on your home? Do you wish you did but can’t afford to buy them or have them made custom? That is where we were last spring. DH loved the idea of shutters, but when we priced them on-line timberlane.com we discovered that they would run between $277 – $400 a piece for solid wood. Since we had 8 windows that needed shutters we had two choices, do without or get busy. DH, my choleric love, got busy. Today’s post will concentrate on just the first few steps. Follow on posts will discuss useful tools and the basics of assembly.
Step 1. Measure the windows from the top of the trim to the bottom and across the same way. We had (6) 60″ x 30″ windows and (2) 78.5″ x 30″ windows.
Step 2. Calculate the finished size by dividing the width by 2. For us that meant each panel needed to be 15″ wide. We wanted the European closed board and batten look. We used stock wood from Home depot and Lowes, pressure treated 1x4s. Did you know that a 1×4 is not actually 4 inches wide. Nope. They were just shy of it so 4 boards across were plenty wide since we were not mounting them on hinges to open and close. Each finished panel was about 14.5. Good, good enough.
Step 3. Decide if you plan on having a ‘breadboard top” – a piece of horizontal wood across the top of the vertical panels. DH wanted this and it did add a nice finish, but it took a good amount of work.Do you want battens – the horizontal pieces. How will you attach the battens? Do you want to cover the nails/screws? We chose to attach the battens with counter-sunk screws and then cover the holes with small wood peg covers we found at Michaels in the wood craft section.
Step 4 – Calculate how many linear feet of wood you will need for each shutter. For example, for each shutter for our 60″ x 30″ windows we needed: 4 long boards cut to 60″ = 240″
1 bread box top = 14.5 ”
2 battens = 29″
for a total of 284.5 inches or roughly 24 linear feet. Multiply this number times 2 for the total per window, multiply by the number of windows of that size. We bought a LOT of wood.
Step 5 – Make bill of materials and purchase. Take the extra time to choose each piece of wood as we found that some of the wood was warped and twisted and we literally had to wrestle it into submission with clamps.
Step 6 – Useful tools - clamps! We could not have made the shutters without clamps. I could go on and on about tools, but must run and finish dinner. More to come!
